Name: Outdoor transparent led screen mesh display panel glass wall curtain for Glass Advertising LED Display
Brand: CONWIN
Price: 1 USD

Home >

Outdoor transparent led screen mesh display panel glass wall curtain for Glass Advertising LED Display

Categories	Outdoor Advertising LED Display
Brand Name:	CONWIN
Model Number:	M10
Certification:	CE,ROHS
Place of Origin:	China
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	2000sqm/month
Delivery Time:	5-8 working days
Packaging Details:	wooden box or carton
Large Viewing Angle:	H: 120°; V : 120°
Led Packing:	Nationstar SMD3535 Black LED
Refresh Frequency:	≥3840Hz
Protection:	IP65
B Chip:	522-531nm
Lifespan:	≥100000hours
Control System:	Nova/Linsn/Colorlight
Panel Material:	steel or Aluminum
Driving Scan:	1/8 scan

Contact Now

Add to Cart

Company Info.

Conwin Optoelectronic Co., Ltd.

Verified Supplier

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Description

1, IP65 Waterproof capacity;

2, front module service

3,non air cooling demand

4,see-throughness /light weight

5,low consumption

Widely installed in hotels,exhibition display,wedding venue,outdoor stage,concert,launch,event,etc

Specification

Parameters	M0612	M0715	M1010	M1212	M1515	M1531
Pixel Pitch(mm)	6.2x12.5mm(H*V)	7.8x15.6mm(H*V)	10x10mm(H*V)	12.5x12.5mm(H*V)	15.6x15.6mm(H*V)	15.6x31.25mm(H*V)
LEDconfiguration	SMD2727	SMD2727	SMD2727	SMD3535	SMD3535	DIP346
Modulesize(mm)	500*125	500*125	500*250	500*125	500*125	500*250
Module resolution	80*10	64*8	50*25	40*10	32*8	32*8
Cabinet size(mm)	1000100085	1000100085	1000100085	1000100085	1000100085	1000100085
Cabinet resolution	160*80	128*64	100*100	80*80	64*64	64*32
Cabinetweight(kg)	19	19	19	19	20	22
Transparency Rate	40%	50%	50%	50%	50%	50%
Brightness(cd/m:)	6000	6000	6000	6000	6000	8000
Max Power Consumption	800w/m2	800w/m2	800w/m2	750w/m2	750w/m2	380w/m2
Avg PowerConsumption	266w/m2	266w/m2	266w/m2	250w/m2	250w/m2	126w/m2
Refresh rate	3840Hz	3840Hz	3840Hz	3840Hz	3840Hz	3840Hz
IP Rating(Front/Rear)	IP65/IP54	IP65/IP54	IP65/IP54	IP65/IP54	IP65/IP54	IP65/IP54
Installation type	Front/Back	Front/Back	Front/Back	Front/Back	Front/Back	Front/Back
Maintenance type	Front/Back	Front/Back	Front/Back	Front/Back	Front/Back	Front/Back
